Dimensions
- dimensions: 4750*1750*1995
- Wheelbase: 2500
- Wheels: 175R14LT 8PR
- Weight (Curb Mass): 2290
Brief introduction
Introduction to Wuhan Junfeng Automobile Co., Ltd
RHD EV RHD Truck chassis
Junfeng RHD EV RHD Truck chassis
Junfeng RHD EV RHD Truck chassis
Colores
RHD EV RHD Truck chassis
RHD EV RHD Truck chassis Specs
Starting at: $
Drive
- Energy: Electric truck
- Range:
- Drive:
- Transmission: Electric vehicle single speed
Power
- Battery type: Lithium iron phosphate battery
- Battery Factory: DongFeng
- Charging:
- Battery capacity: 81.3
Cockpit
- Seat:
- Displays:
- luggage volume:
- Airbag: Standard
Performance
- High Speed: 95
- Acceleration: 0
- Intelligent assisted driving:
- Air conditioning: Standard
Warranty
- Basic Vehicle:
RHD EV RHD Truck chassis
| 底盘技术参数 Chassis Parameters | ||||||
| 名称 Name |
（右舵）纯电动载货汽车底盘 (right-hand drive) pure electric cargo truck chassis |
|||||
|
外形尺寸 Size（mm） |
长 length | 4750 | 轮胎规格 tire specification | 175R14LT 8PR | ||
| 宽 width | 1750 |
轮胎数（个） Number of tires (pcs) |
6 | |||
| 高 height | 1995 |
钢板弹簧片数 Number of steel plate springs |
6/5+1 | |||
| 轴距 wheelbase | 2500 |
最高车速（km/h） Maximum speed (km/h) |
95 | |||
|
续驶里程（km） Driving range (km) |
320 | |||||
|
货厢尺寸 cargo size |
长 | / |
接近角/离去角（°） Approach angle/departure angle (°) |
16/22 | ||
| 宽 | / | 乘员人数 Number of passengers | 2 | |||
| 高 | / | 燃料 fuel type | 纯电动 EV | |||
|
轮距 track wide |
前轮 | 1460 | 充电方式/充电时间（h） | 快充/1 | ||
| 后轮 | 1360 |
电机控制器 motor controller |
型号 model | KTZ34X29STY50 | ||
| 前悬 front overhang | 1030 |
生产企业 manufacturer |
武汉理工通宇新源动力有限公司 Wuhan Institute of Technology Tongyu Xinyuan Power Co., Ltd |
|||
| 后悬 rear overhang | 1220 |
电机 motor |
型号 model | TZ210XSTY5308 | ||
| 质量参数（kg） | 总质量 total mass | 3495 |
生产企业 manufacturer |
武汉理工通宇新源动力有限公司 Wuhan Institute of Technology Tongyu Xinyuan Power Co., Ltd |
||
| 整备质量 curb weight | 2290 |
额定功率 rated power（kw） |
55 | |||
| 额定载质量 rated load capacity | / |
电池 battery |
种类 type |
磷酸铁锂蓄电池 lithium iron phosphate |
||
|
轴荷分配 Axle load distribution |
前轴 front axle |
1405 |
生产企业 manufacturer |
苏州新中能源科技有限公司 | ||
|
后轴 rear axle |
2090 | 容量 capacity（kwh) | 81.3 | |||
